UA-250

Multi-Axis Machine for Mass Production

ITEM/MODEL UA-250
Controller FANUC 0i-T
CAPACITY
Swing over bed mm 700
Swing over saddle mm 600
Max. Turning Diameter (SP1) mm 360
Max. Turning Diameter (SP2) mm 360
Max. turning length mm 290
Guide way type Box
SPINDLE 1
Spindle Nose ASA A2-11
Chuck Diameter inch 15
Bar Capacity mm 105
Spindle Speed rpm 2500
Spindle Motor Power(Cont. /30min) kW 15/18.5
SPINDLE 2
Spindle Nose ASA A2-11
Chuck Diameter inch 15
Bar Capacity mm 105
Spindle Speed rpm 2500
Spindle Motor Power(Cont. /30min) kW 15/18.5
TRAVELS
X-axis Travel mm X1/X2: 190
Z-axis Travel mm Z1/Z2: 500
Y-axis Travel mm -
B-axis Travel mm 1200
FEED RATES
X-axis Rapid Traverse Rate m/min 20
Z-axis Rapid Traverse Rate m/min 30
Y-axis Rapid Traverse Rate m/min -
B-axis Rapid Traverse Rate m/min 20
TURRET
Tooling system BMT-55N
Turret driven type Servo mechanical
Number of tools station 12+12
Square tool shank size mm 25
Round tool shank size mm 40
Max. Rotary Tool Speed rpm -
Rotary Tool power kW -
DIMENSION
Machine dimension L x W xH m 5.6 x 2.6 x 2.4
Net weight kg 11000
