JT-150
Slant Bed Linear Way CNC Lathe
Best Structural Reliability and High Precision Linear Way Performance
· Cam-driven hydraulic/servo turret with 8/10/12 station
· One-piece bed, 45° slant-bed structural design
· Max. Swing: 505 mm
· Max. Length: 320/260 mm
· Spindle: A2-5/A2-6 in 6000/4500 rpm
· Bar capacity: 44 mm
· 8.4"Fanuc 0i controller with color LCD monitor
· Cam-driven hydraulic/servo turret with 8/10/12 station
· One-piece bed, 45° slant-bed structural design
· Max. Swing: 505 mm
· Max. Length: 320/260 mm
· Spindle: A2-5/A2-6 in 6000/4500 rpm
· Bar capacity: 44 mm
· 8.4"Fanuc 0i controller with color LCD monitor
|
|
ITEM/MODEL | JT-150 | |
|---|---|---|---|
|
|
Controller | FANUC 0i-T | |
|
|
CAPACITY | ||
|
|
Swing over bed | mm | 505 |
|
|
Swing over saddle | mm | 318 |
|
|
Max. turning diameter | mm | 350/300(320) |
|
|
Max. turning length | mm | 320 |
|
|
Guide way type | Linear | |
|
|
SPINDLE | ||
|
|
Spindle nose taper | ASA | A2-6(A2-5) |
|
|
Chuck diameter | inch | 8(6) |
|
|
Spindle hole diameter | mm | 62(56/76) |
|
|
Spindle speed | rpm | 4500(6000/4000) |
|
|
Spindle motor power(Cont. / 30min) | kW | 7.5/11 (11/15) |
|
|
Bar capacity | mm | 52(44/65) |
|
|
TRAVELS | ||
|
|
Z-axis Travel | mm | 350 |
|
|
X-axis Travel | mm | 195 |
|
|
FEED RATES | ||
|
|
Z-axis Rapid Traverse Rate | m/min | 30 |
|
|
X-axis Rapid Traverse Rate | m/min | 30 |
|
|
TURRET | ||
|
|
Tooling system | BOT | |
|
|
Turret driven type | Hydraulic/Servo | |
|
|
Number of tools | station | 8/10(12) |
|
|
Square tool shank size | mm | 25(20) |
|
|
Round tool shank size | mm | 32 |
|
|
TAILSTOCK | ||
|
|
Tailstock body travel | mm | 200 |
|
|
Quill travel | mm | 150 |
|
|
Quill diameter | mm | 70 |
|
|
Quill taper | MT# | 4 |
|
|
DIMENSION | ||
|
|
Machine dimension L x W x H | m | 2.3 x 1.7 x 1.8 |
|
|
Net weight | kg | 2900 |
|
|
NO. | STANDARD ACCESSORIES | NO. | OPTIONAL ACCESSORIES |
|---|---|---|---|---|
|
|
1 | FANUC 0i-T controller | 1 | Upgrade to 10.4" Colored LCD monitor |
|
|
2 | RS-232 interface | 2 | Collet chuck |
|
|
3 | Rigid tapping | 3 | Tool setter |
|
|
4 | Heat exchanger for electric cabinet | 4 | Parts catcher and parts conveyor |
|
|
5 | 8.4" Colored LCD monitor | 5 | Bar feeder interface (7 or 24 pins) |
|
|
6 | Lubrication system | 6 | Bar feeder |
|
|
7 | 4-bar coolant system | 7 | Oil mist collector |
|
|
8 | Three-color warning light | 8 | Oil-coolant skimmer |
|
|
|
9 | Air cooler for electric cabinet | |
|
|
10 | Transformer | ||
|
|
11 | CE version | ||
|
|
12 | Loader interface | ||
|
|
13 | Gantry loader system | ||
|
|
14 | Automatic door |
45°Slant Bed Design
The integral type lathe bed makes the machine more rigid and stable. The 45 degree slant bed is very convenient to discharge chips.
Belt Type Driven Spindle
Spindle is supported by a double row of taper roller bearings in the front and rear side to resist axial cutting force, while self-alignment angular contact bearings provide tremendous radial load capacity. Precise balance is performed on each spindle to reduce the vibration and runout by enhancing performance and overall quality.
Skilled Hand Scraping Process
During assembly process, flatness, perpendicularity and straightness is regularly checked and skilled hand scrapped to deliver the excellent geometry accuracy that Accuway lathes are renowned for.
High-Precision Linear Guide Way Design
Linear guide way design provides low friction coefficient, and minimize the difference between dynamic and static friction. Therefore, the stick-slip will not occur during sub-micron feeding.
Ballscrew Drive Mechanism
Oversized AC servo motors are used to deliver powerful thrust for high feedrates and accurate cutting. Large diameter pre-tensioned precision ballscrews are directly connected to the drive mechanism for nearly backlash free movement.
Programmable Tailstock
The tailstocks on the JT series machines can be either manually or automatically programmable controlled.
They are located on the same one-piece cast guideway surface as the headstock and main spindle.
Precision In-house Turret Assembly
All turrets are built with robust design and both hydraulic and servo-mechanical power turrets are available to cover a wide range of application including an optional BMT turret.
