JT-200/JT-200M

Slant Bed Linear Way CNC Lathe

ITEM/MODEL JT-200 JT-200M
Controller FANUC 0i-T
CAPACITY
Swing over bed mm 505 505
Swing over saddle mm 318 318
Max. turning diameter mm 300 230
Max. turning length mm 560 450
Guide way type Linear
SPINDLE
Spindle nose taper ASA A2-5 A2-6 A2-5 A2-6
Chuck diameter inch 6 8 6 8
Bar capacity mm 44 52 65 44 52 65
Spindle speed rpm 6000 4500 4000 6000 4500 4000
Spindle motor power(Cont. / 30min) kW 11/15 11/15
TRAVELS
X-axis Travel mm 195 195
Z-axis Travel mm 600 600
Y-axis Travel mm - -
FEED RATES
X-axis Rapid Traverse Rate m/min 30 30
Z-axis Rapid Traverse Rate m/min 30 30
Y-axis Rapid Traverse Rate m/min - -
TURRET
Tooling system BOT -
Turret driven type Hydraulic/Servo Servo mechanical
Number of tools station 8 10 12 12
Square tool shank size mm 25 25 20 20
Round tool shank size mm 32 32
Max. Rotary Tool Speed rpm - 6000
Rotary Tool power kW - 4.5
TAILSTOCK
Tailstock body travel mm 450 450
Quill travel mm 150 150
Quill diameter mm 70 70
Quill taper MT# 4 4
DIMENSION
Machine dimension L x W x H m 2.5 x 1.7 x 1.8 2.5 x 1.7 x 1.9
Net weight kg 3200 3300




NO. STANDARD ACCESSORIES NO. OPTIONAL ACCESSORIES
1 FANUC 0i-T controller 1 Upgrade to 15" Colored LCD monitor
2 RJ-45 interface 2 Collet chuck
3 Rigid tapping 3 Tool setter
4 Heat exchanger for electric cabinet 4 Parts catcher and parts conveyor
5 10.4" Colored LCD monitor 5 Bar feeder interface (7 or 24 pins)
6 Lubrication system 6 Bar feeder
7 4-bar coolant system 7 Oil mist collector
8 Three-color warning light 8 Oil-coolant skimmer
9 Air cooler for electric cabinet
10 Transformer
11 CE version
12 Loader interface
13 Gantry loader system
14 Automatic door
