UV-75ATCC
Vertical Turning Center
Heavy Duty Cutting Spindle Design on Vertical Turning Center
· ATC-BT50 live tool turret with 12 station
· Robust and rigid structural design
· Linear guide way type or box way type
· Max. Swing: 850 mm
· Max. Length: 800 mm
· Spindle: A2-11 in 1600 rpm
· 8.4"Fanuc 0i controller with color LCD monitor
· ATC-BT50 live tool turret with 12 station
· Robust and rigid structural design
· Linear guide way type or box way type
· Max. Swing: 850 mm
· Max. Length: 800 mm
· Spindle: A2-11 in 1600 rpm
· 8.4"Fanuc 0i controller with color LCD monitor
|
|
ITEM/MODEL | UV-75ATCC |
|
|
|---|---|---|---|---|
|
|
Controller | FANUC 0i-T | ||
|
|
CAPACITY | |||
|
|
Swing over bed | mm | 850 | |
|
|
Max. turning diameter | mm | 750 | |
|
|
Max. turning length | mm | 800 | |
|
|
SPINDLE | |||
|
|
Spindle Speed | rpm | 1600 | |
|
|
Spindle drive system | belt | ||
|
|
Spindle bearing diameter | mm | 160 | |
|
|
Spindle Motor Power(Cont. /30min) | kW | 18.5/22 | |
|
|
Spindle nose taper | ASA | A2-11 | |
|
|
Chuck diameter | inch | 24(32) | |
|
|
TOOL SPINDLE | |||
|
|
Spindle taper | BT50 | ||
|
|
Max. spindle speed | 3000 |
|
|
|
|
Spindle drive system | belt | ||
|
|
Spindle bearing diameter | mm | 100 | |
|
|
Spindle Motor Power(Cont. /30min) | kW | 5.5/7.5 | |
|
|
Max. spindle torque | N-m | 105 | |
|
|
TRAVELS | |||
|
|
X-axis Travel | mm | 650 | |
|
|
Z-axis Travel | mm | 800 | |
|
|
X-axis ballscrew diameter | mm | 50 | |
|
|
Z-axis ballscrew diameter | mm | 50 | |
|
|
Guide way type | Linear(Box) | ||
|
|
FEEDS | |||
|
|
X-axis Rapid Traverse Rate | m/min | 20 | |
|
|
Z-axis Rapid Traverse Rate | m/min | 24 | |
|
|
TURRET | |||
|
|
Tooling system | ATC | ||
|
|
Indexing type | Servo-gear | ||
|
|
Turret driven type | Servo mechanical | ||
|
|
Number of tools | station | 12 | |
|
|
Tool holder taper size | BT50 | ||
|
|
Max. tool length | mm | 400 | |
|
|
Max. tool weight | kg | 50 | |
|
|
Max. magazine load | kg | 420 | |
|
|
MOTOR | |||
|
|
Spindle motor | kW | 18.5/22 | |
|
|
X-axis motor power | kW | 3 | |
|
|
Z-axis motor power | kW | 4 | |
|
|
Hydraulic motor power | kW | 2.2 | |
|
|
Coolant pump motor power | kW | 0.5+1 | |
|
|
Tool spindle power | kW | 5.5/7.5 | |
|
|
DIMENSION | |||
|
|
Machine dimension L x W x H | m | 3.6 x 2.7 x 4 | |
|
|
Net weight | kg | 16500 |
|
|
|
NO. | STANDARD ACCESSORIES | NO. | OPTIONAL ACCESSORIES |
|---|---|---|---|---|
|
|
1 | FANUC 0i-T controller | 1 | Upgrade to 10.4" Colored LCD monitor |
|
|
2 | RS-232 interface | 2 | Tool setter |
|
|
3 | Rigid tapping | 3 | Oil mist collector |
|
|
4 | Heat exchanger for electric cabinet | 4 | Oil-coolant skimmer |
|
|
5 | 8.4" Colored LCD monitor | 5 | Air cooler for electric cabinet |
|
|
6 | Lubrication system | 6 | Gearbox |
|
|
7 | 4-bar coolant system | 7 | Upgrade to non-through hole 3-jaw 32" hydraulic chuck & cylinder |
|
|
8 | Cutter air blast | 8 | Transformer |
|
|
9 | Spray gun | 9 | CE version |
|
|
10 | Three-color warning light | 10 | Tool Holder |
Structure
Accuway vertical turning center UV series are designed and built to withstand the most demanding applications in various industries.
UV series lathes offer highefficiency, high-accuracy, excellent rigidity and great stability.
Meehanite castings are internally reinforced with heavy ribs to resist bending and damp vibrations. Symmetric ribs not only increase rigidity but improve thermal stability.
Massive base and column further decrease natural frequency, ensuring precise accuracy and repeatability.
Main Spindle
Large diameter main spindle bearing combining with wide range torque spindle motor offers highest rigidity while machining.
Its strong structure further provides vibration absorption under the most demanding conditions to obtain excellent accuracy of versatile work- pieces.
Second Spindle
Hardened, ground and balanced second-spindle is firmly encased in the robust saddle to withstand heavy duty machining. The power is transmitted to second-spindle through special transmission reduction generating enough speed and torque to satisfy wide spectrum of tough machining requirements.
Model ATCC has milling second-spindle that involves drilling, milling and tapping and is capable to complete a part without any secondary operations. Dual contact “Big Plus” type spindle system is available as an option to provide excellent repeatability and rigidity for upgrading machine performance.
Automatic Tool Changer (ATC)
Hybrid 12-tool magazine ATC design of fers multiple machining capacity: turning, milling, drilling and rigid tapping operations while integrated with second spindle and live toolings. It eliminates secondary operations and increase productivity by reducing loading & unloading and fixture cost.
Main Features
Heavy duty cutting spindle design
Strong rigid bearing structure allows heavy duty cutting under workpiece self-weight with asymmetric geometry while performing excellent accuracy. It must pass through contionuous run-in test to reach smooth mating tolerance between spindle shaft and support bearings to withstand high vibration and heat distortion.
Large diameter main spindle bearing combining powerful wide range torque spindle motor offers highest rigidity to satisfy versatile cutting requirements.
Reliable hydro-mechanical turret
Applies hydraulic motor with cam mechanism designed for fast, smooth and precise indexing. It has large diameter curvic coupling for tool clamping under heavy-duty machining.
Bolt-on or VDI tooling systems are available for proper tool holders selection satisfying most machining processes.
Hybrid machining capability
Hybrid ATC design offers multiple machining functions such as turning, millimg, drilling and rigid tapping operations if integrated with subspindle and live toolings. It also eliminate secondary operations and increase productivity by reducing time of loading & unloading and fixture cost.
C-axis provides indexing resolution of 0.01 degree per increment. Contouring, complex round and prismatic machining, rectangular slot and lettering are accomplished by synchronizing the spindle with the X and Z axis. Rigid tapping can be done with both cylindrical and end-working surfaces.
ATC
The 12-tool magazine meets the demands of various machining operations and being convenient for fast tool selection and easy operation.
Accuway vertical turning center UV series are designed and built to withstand the most demanding applications in various industries.
UV series lathes offer highefficiency, high-accuracy, excellent rigidity and great stability.
Meehanite castings are internally reinforced with heavy ribs to resist bending and damp vibrations. Symmetric ribs not only increase rigidity but improve thermal stability.
Massive base and column further decrease natural frequency, ensuring precise accuracy and repeatability.
Main Spindle
Large diameter main spindle bearing combining with wide range torque spindle motor offers highest rigidity while machining.
Its strong structure further provides vibration absorption under the most demanding conditions to obtain excellent accuracy of versatile work- pieces.
Second Spindle
Hardened, ground and balanced second-spindle is firmly encased in the robust saddle to withstand heavy duty machining. The power is transmitted to second-spindle through special transmission reduction generating enough speed and torque to satisfy wide spectrum of tough machining requirements.
Model ATCC has milling second-spindle that involves drilling, milling and tapping and is capable to complete a part without any secondary operations. Dual contact “Big Plus” type spindle system is available as an option to provide excellent repeatability and rigidity for upgrading machine performance.
Automatic Tool Changer (ATC)
Hybrid 12-tool magazine ATC design of fers multiple machining capacity: turning, milling, drilling and rigid tapping operations while integrated with second spindle and live toolings. It eliminates secondary operations and increase productivity by reducing loading & unloading and fixture cost.
Main Features
Heavy duty cutting spindle design
Strong rigid bearing structure allows heavy duty cutting under workpiece self-weight with asymmetric geometry while performing excellent accuracy. It must pass through contionuous run-in test to reach smooth mating tolerance between spindle shaft and support bearings to withstand high vibration and heat distortion.
Large diameter main spindle bearing combining powerful wide range torque spindle motor offers highest rigidity to satisfy versatile cutting requirements.
Reliable hydro-mechanical turret
Applies hydraulic motor with cam mechanism designed for fast, smooth and precise indexing. It has large diameter curvic coupling for tool clamping under heavy-duty machining.
Bolt-on or VDI tooling systems are available for proper tool holders selection satisfying most machining processes.
Hybrid machining capability
Hybrid ATC design offers multiple machining functions such as turning, millimg, drilling and rigid tapping operations if integrated with subspindle and live toolings. It also eliminate secondary operations and increase productivity by reducing time of loading & unloading and fixture cost.
C-axis provides indexing resolution of 0.01 degree per increment. Contouring, complex round and prismatic machining, rectangular slot and lettering are accomplished by synchronizing the spindle with the X and Z axis. Rigid tapping can be done with both cylindrical and end-working surfaces.
ATC
The 12-tool magazine meets the demands of various machining operations and being convenient for fast tool selection and easy operation.
- Maximum weight of single tool holder: 50kg
- Maximum rotary tool poewr: 7.5kW
- Tool holder taper: BT-50
- Tool magazine indexing mechanism: cam
